Understanding when and how to incorporate existing user interfaces into new medical devices can streamline development while maintaining safety and regulatory compliance.

Introduction

In a recent article, "The Perils of Medical Device Predicates and User Interface Design," my colleague Jenny Collinson, Director of Strategy and Advisory, described the potential pitfalls associated with the predicate pathway 510(k). These streamlined regulatory processes often end up being the preferred method for manufacturers, as they have the potential to reduce the product in question's time to market and the associated budget.

One of the ways to streamline user interface (UI) development is to inherit aspects of the UI from previous designs. This is where the concept of User Interface of Unknown Provenance (UOUP) can come into play—a framework that allows manufacturers to justify existing user interfaces when complete documentation of their usability engineering process is unavailable. But when is this approach appropriate?

Firstly, what is UOUP?

UOUP refers to user interfaces or components of user interfaces that are incorporated into medical devices without complete documentation of their usability engineering process. The UOUP approach applies to user interfaces or part of user interfaces that have been commercialized prior to the publication of IEC 62366-1:2015.

Benefits and Limitations

Benefits:

  • Reduces redundant design and testing efforts - Eliminates the need to recreate interfaces that have already proven effective.

  • Allows for leveraging well-established interfaces with proven clinical use - Takes advantage of interfaces that healthcare providers already understand and trust.

  • Saves development time and resources - Shortens the development cycle by building on existing work.

  • Maintains consistency with interfaces that users are already familiar with - Reduces training needs and potential user errors.

Limitations:

  • Requires significant post-market data to justify the approach - Must demonstrate safety through real-world usage evidence.

  • May not be suitable for high-risk devices or functions - Higher risk classifications may demand more rigorous documentation.

  • Limited applicability when substantial changes are made to the interface - Major modifications may nullify the benefits of using UOUP.

  • Requires thorough risk analysis and supplementary testing - Still demands careful evaluation of potential use errors.

The UOUP Framework in Practice

The UOUP approach as outlined in IEC 62366 enables manufacturers to leverage existing legacy user interfaces or parts thereof for new product development, provided that the legacy user interface remains unchanged. However, it requires robust post-market surveillance of the legacy device to determine that there are no safety-related use risks associated with the existing legacy user interface. The UOUP approach aims at building a robust justification for not requiring validation on unchanged elements of the user interface.

Looking Beyond: The Evolution of UOUP in a Post-2015 World

Changing Documentation Expectations

What happens to the UOUP framework as more devices designed under the full IEC 62366-1:2015 paradigm enter the market?

The UOUP concept was born out of necessity—addressing the reality that many interfaces were developed before comprehensive usability engineering documentation was required. But as we approach the decade mark since the introduction of IEC 62366-1:2015, we're entering uncharted territory. Soon, manufacturers will be looking to leverage user interfaces that were ostensibly developed with full usability engineering processes—yet documentation gaps may still exist due to acquisitions, staff turnover, or simply the passage of time.

Future Regulatory Considerations

Will the UOUP approach evolve to accommodate these "second-generation" documentation challenges? Or will regulatory bodies expect more robust documentation preservation for interfaces developed in the post-2015 era? Perhaps most importantly: will the very definition of "unknown provenance" need to shift when the unknown shouldn't, in theory, exist?

As manufacturers and regulatory professionals, we may soon find ourselves advocating for a more nuanced understanding of UOUP—one that acknowledges that even in our documentation-heavy world, gaps can and will occur. The challenge ahead lies not just in following today's UOUP guidance, but in shaping its evolution to remain practical while ensuring patient safety in an increasingly complex technological landscape.

Moving Forward

What documentation preservation strategies should your organization implement today to avoid UOUP challenges tomorrow? And how might we collectively influence the regulatory approach to ensure innovation doesn't become buried under unrealistic documentation expectations? Consider developing comprehensive documentation archives and engaging with regulatory bodies early to help shape the future of UOUP implementation.

Navigating UOUP With Confidence

Facing challenges with legacy interfaces in your medical device development? The regulatory landscape is complex, but you don't have to navigate it alone. Our team at ClariMed brings decades of combined experience in medical device usability engineering and regulatory strategy. We're happy to share insights on your specific UOUP questions during a no-obligation consultation. Reach out to continue the conversation about balancing innovation with compliance in your next development project.
